A production-ready e-commerce order processing system built with Azure Functions, Service Bus, and Next.js. This project demonstrates enterprise-grade cloud-native patterns including event-driven architecture, Infrastructure as Code, and complete observability.
Key Features
- Event-Driven Architecture: Asynchronous order processing using Azure Service Bus queues
- Serverless Backend: Four Azure Functions (TypeScript) handling HTTP triggers, queue processing, dead letter handling, and health checks
- Modern Frontend: Next.js application with React Hook Form, Zod validation, and TanStack Query
- Infrastructure as Code: Complete Azure infrastructure defined in Bicep with modular design
- Full Observability: Application Insights integration with custom events, metrics, and KQL queries
- Automated CI/CD: GitHub Actions workflows for infrastructure and application deployment
- Error Handling: Automatic retry logic, dead letter queue processing, and circuit breaker pattern
- Production-Ready: Comprehensive security, validation, testing, and monitoring
Tech Stack
Backend:
- Azure Functions (Node.js runtime)
- TypeScript
- Azure Service Bus
- Application Insights
- Zod for validation
Frontend:
- Next.js with App Router
- React Hook Form
- TanStack Query
- shadcn/ui components
- Dark mode support
Infrastructure:
- Bicep (Infrastructure as Code)
- Azure Resource Manager
- GitHub Actions for CI/CD
Architecture
The system implements the Queue-Based Load Leveling pattern with Competing Consumers:
- Frontend submits orders via HTTP to an Azure Function
- HTTP Trigger Function validates the order and publishes it to Service Bus
- Service Bus Queue stores messages reliably with automatic retry
- Queue Trigger Function processes orders asynchronously
- Dead Letter Processor handles failed messages after max retries
- Application Insights tracks all events, metrics, and errors
This architecture provides:
- Decoupling: Frontend and backend are completely independent
- Reliability: Messages persist if processing fails
- Scalability: Multiple consumers process messages in parallel
- Resilience: Automatic retry with exponential backoff
- Performance: Fast user response times with async processing
Infrastructure as Code
All Azure resources are defined in Bicep modules:
- Service Bus: Queue with production-ready settings (10 max retries, 5-minute lock duration, 14-day TTL)
- Function App: Pre-configured with Application Insights, Service Bus connection, and environment settings
- Application Insights: Monitoring with custom events and KQL queries
- Storage Account: Required for Azure Functions runtime
- Static Web App: Hosting for the Next.js frontend
The infrastructure supports multiple environments (dev, staging, prod) through parameterized deployments.
Error Handling & Resilience
- Automatic Retries: Service Bus retries failed messages up to 10 times with exponential backoff
- Dead Letter Queue: Messages that fail after max retries move to DLQ for investigation
- Circuit Breaker: Prevents cascading failures when external services are unavailable
- Transient Fault Handling: Differentiates between transient (retry) and permanent (DLQ) errors
- Health Checks: Endpoint for monitoring system health and configuration
Observability
Comprehensive monitoring through Application Insights:
- Custom Events: OrderSubmitted, OrderProcessed with order details
- Exceptions: Tracked with context (orderId, error type, delivery count)
- Metrics: Processing duration, queue depth, error rates
- KQL Queries: Pre-built queries for submission rate, average processing time, and error analysis
- Alerts: Configurable alerts for high error rates, slow processing, and queue depth
Deployment
One-command deployment script:
./scripts/deploy-local.sh dev
This deploys:
- Complete Azure infrastructure (5-7 minutes)
- Backend Azure Functions (2-3 minutes)
- Frontend Next.js application (if configured)
Cost estimate: ~$11-21/month for development environment using free tiers.
Security
- Authentication: Function-level authentication with Azure Functions keys
- Validation: Zod schemas for type-safe input validation
- Secrets Management: Azure Key Vault integration for connection strings
- CORS: Configured to allow specific origins only
- HTTPS: Enforced on all services
- Managed Identity: For secure service-to-service authentication
Testing
- Unit Tests: Test individual functions with mocked dependencies
- Integration Tests: End-to-end order flow validation
- Type Safety: TypeScript ensures compile-time type checking
- Schema Validation: Zod schemas shared between frontend and backend
